PUMA560运动学分析
参考教材：《机器人学第三版蔡自兴》
PUMA560建模与仿真matlab代码
matlab工具箱：robotics toolbox
①下载地址 http://petercorke.com/wordpress/toolboxes/robotics-toolbox 下载安装包(.zip)格式的,将解压后的文件夹” rvctools"复制到 matlab安装路径下的 toolbox文件夹中。
②打开 matlab,点击设置路径->>添加并包含子文件夹,然后选择这 个" rvctools"文件夹,最后保存->>关闭
③打开”rvctool"文件夹的 startup_rvc. m运行,此时roboticstoolbox安装完毕。或者在 matlab命令行输入 startup rvc安装。
④matlab命令行输入ver查看是否安装
>>ver
MATLAB 版本: 9.5.0.944444 (R2018b)
Robotics Toolbox for MATLAB 版本 10.3.1
程序说明
- 根据教材上的公式推导，能计算出机器人的四组解，再根据腕关节的"翻转"，能得到另外四组解。（共8组解）。在规划过程中只采用了一组解，并未筛选出最优解。（其余的解被我注释掉了，感兴趣的话，可以用其余的解运行尝试一下👏）
主程序
% 轨迹规划中，首先建立机器人模型，6R机器人模型，名称modified puma560。
% 定义机器人 a--连杆长度，d--连杆偏移量
a2=0.4318;a3=0.02032;d2=0.14909;d4=0.43307;
% thetai di ai-1 alphai-1
L1 = Link([pi/2 0 0 0], 'modified');
L2 = Link([0 d2 0 -pi/2], 'modified');
L3 = Link([-pi/2 0 a2 0], 'modified');
L4 = Link([0 d4 a3 -pi/2], 'modified');
L5 = Link([0 0 0 pi/2], 'modified');
L6 = Link([0 0 0 -pi/2], 'modified');
robot = SerialLink([L1,L2,L3,L4,L5,L6]);
robot.name = 'modified puma560';
% robot.display();
% robot.teach();
% 定义轨迹规划中初始关节角度（First_Theta）和终止关节角度（Final_Theta）、步数777。
% First_Theta = [0 pi/2 -pi/2 0 0 0];%就绪状态
% Final_Theta = [0 pi/4 pi 0 pi/4 0];%灵巧状态
% 6角度变化
First_Theta = [0 pi/2 -pi/2 0 0 0];
Final_Theta = [pi/6 pi/4 pi pi/3 pi/4 pi/2];
% jtraj函数关节角空间轨迹规划
step = 777;
[q,qd,qdd] = jtraj(First_Theta,Final_Theta,step);
%平面中一共分成2*4=8个子画图区间，一共两行，每行四个
%在第一行第1个子图画位置信息。
subplot(2,4,1);
i = 1:6;
plot(q(:,i)); grid on;
title('位置');
%在第一行第2个子图画速度信息。
subplot(2,4,2);
i = 1:6;
plot(qd(:,i));grid on;
title('速度');
%在第二行第1个子图画加速度信息。
subplot(2,4,5);
i = 1:6;
plot(qdd(:,i));grid on;
title('加速度');
%根据First_Theta和Final_Theta得到起始和终止的位姿矩阵。
%运用自带函数求解
% T0 = robot.fkine(First_Theta);
% Tf = robot.fkine(Final_Theta);
%根据改进DH模型的自编函数，kinematics正运动学求解
T0=kinematics(First_Theta);
T0=SE3(T0);
Tf=kinematics(Final_Theta);
Tf=SE3(Tf);
%利用ctraj在笛卡尔空间规划轨迹。
Tc = ctraj(T0,Tf,step);
%在齐次旋转矩阵中提取移动变量，相当于笛卡尔坐标系的点的位置。
Tjtraj = transl(Tc);
%在第二行第2个子图画p1到p2直线轨迹。
subplot(2,4,6);
plot2(Tjtraj,'r');grid on;
title('T0到Tf直线轨迹');
% hold on;
%在第一行三四子图和第二行三四子图，就相当于整个的右半部分画图
subplot(2,4,[3,4,7,8]);
for Var = 1:777
T1=Tc(1,Var);
T2=T1.T;
% Inverse_kinematics逆运动学求解
qq(:,Var) = Inverse_kinematics(T2);
end
plot2(Tjtraj,'r');
robot.plot(qq');
kinematics 函数 (正运动学)
function T0_6=kinematics(theta1_6)
a2=0.4318;a3=0.02032;d2=0.14909;d4=0.43307;
theta1=theta1_6(1);
theta2=theta1_6(2);
theta3=theta1_6(3);
theta4=theta1_6(4);
theta5=theta1_6(5);
theta6=theta1_6(6);
c1=cos(theta1);s1=sin(theta1);
c2=cos(theta2);s2=sin(theta2);
c3=cos(theta3);s3=sin(theta3);
c4=cos(theta4);s4=sin(theta4);
c5=cos(theta5);s5=sin(theta5);
c6=cos(theta6);s6=sin(theta6);
%6个连杆变换矩阵
T1=[c1 -s1 0 0;s1 c1 0 0;0 0 1 0;0 0 0 1];
T2=[c2 -s2 0 0;0 0 1 d2;-s2 -c2 0 0;0 0 0 1];
T3=[c3 -s3 0 a2;s3 c3 0 0 ;0 0 1 0;0 0 0 1];
T4=[c4 -s4 0 a3;0 0 1 d4;-s4 -c4 0 0;0 0 0 1];
T5=[c5 -s5 0 0 ;0 0 -1 0;s5 c5 0 0;0 0 0 1];
T6=[c6 -s6 0 0 ;0 0 1 0;-s6 -c6 0 0;0 0 0 1];
%正运动学方程
T0_6 = T1*T2*T3*T4*T5*T6;
end
Inverse_kinematics 函数（逆运动学）
function theta_Med=Inverse_kinematics(T)
% a--连杆长度，d--连杆偏移量
a2=0.4318;a3=0.02032;d2=0.14909;d4=0.43307;
nx=T(1,1); ny=T(2,1); nz=T(3,1);
ox=T(1,2); oy=T(2,2); oz=T(3,2);
ax=T(1,3); ay=T(2,3); az=T(3,3);
px=T(1,4); py=T(2,4); pz=T(3,4);
% 为方便计算，定义的m系列向量
% 求解关节角1
theta1_1 = atan2(py,px)-atan2(d2,sqrt(px^2+py^2-d2^2));
theta1_2 = atan2(py,px)-atan2(d2,-sqrt(px^2+py^2-d2^2));
% 求解关节角3
m3_1 = (px^2+py^2+pz^2-a2^2-a3^2-d2^2-d4^2)/(2*a2);
theta3_1 = atan2(a3,d4)-atan2(m3_1,sqrt(a3^2+d4^2-m3_1^2));
theta3_2 = atan2(a3,d4)-atan2(m3_1,-sqrt(a3^2+d4^2-m3_1^2));
% 求解关节角2
ms2_1 = -((a3+a2*cos(theta3_1))*pz)+(cos(theta1_1)*px+sin(theta1_1)*py)*...
(a2*sin(theta3_1)-d4);
mc2_1 = (-d4+a2*sin(theta3_1))*pz+(cos(theta1_1)*px+sin(theta1_1)*py)*...
(a2*cos(theta3_1)+a3);
theta23_1 = atan2(ms2_1,mc2_1);
theta2_1 = theta23_1 - theta3_1;
ms2_2 = -((a3+a2*cos(theta3_1))*pz)+(cos(theta1_2)*px+sin(theta1_2)*py)*...
(a2*sin(theta3_1)-d4);
mc2_2 = (-d4+a2*sin(theta3_1))*pz+(cos(theta1_2)*px+sin(theta1_2)*py)*...
(a2*cos(theta3_1)+a3);
theta23_2 = atan2(ms2_2,mc2_2);
theta2_2 = theta23_2 - theta3_1;
ms2_3 = -((a3+a2*cos(theta3_2))*pz)+(cos(theta1_1)*px+sin(theta1_1)*py)*...
(a2*sin(theta3_2)-d4);
mc2_3 = (-d4+a2*sin(theta3_2))*pz+(cos(theta1_1)*px+sin(theta1_1)*py)*...
(a2*cos(theta3_2)+a3);
theta23_3 = atan2(ms2_3,mc2_3);
theta2_3 = theta23_3 - theta3_2;
ms2_4 = -((a3+a2*cos(theta3_2))*pz)+(cos(theta1_2)*px+sin(theta1_2)*py)*...
(a2*sin(theta3_2)-d4);
mc2_4 = (-d4+a2*sin(theta3_2))*pz+(cos(theta1_2)*px+sin(theta1_2)*py)*...
(a2*cos(theta3_2)+a3);
theta23_4 = atan2(ms2_4,mc2_4);
theta2_4 = theta23_4 - theta3_2;
% 求解关节角4
ms4_1=-ax*sin(theta1_1)+ay*cos(theta1_1);
mc4_1=-ax*cos(theta1_1)*cos(theta23_1)-ay*sin(theta1_1)*...
cos(theta23_1)+az*sin(theta23_1);
theta4_1=atan2(ms4_1,mc4_1);
ms4_2=-ax*sin(theta1_2)+ay*cos(theta1_2);
mc4_2=-ax*cos(theta1_2)*cos(theta23_2)-ay*sin(theta1_2)*...
cos(theta23_2)+az*sin(theta23_2);
theta4_2=atan2(ms4_2,mc4_2);
ms4_3=-ax*sin(theta1_1)+ay*cos(theta1_1);
mc4_3=-ax*cos(theta1_1)*cos(theta23_3)-ay*sin(theta1_1)*...
cos(theta23_3)+az*sin(theta23_3);
theta4_3=atan2(ms4_3,mc4_3);
ms4_4=-ax*sin(theta1_2)+ay*cos(theta1_2);
mc4_4=-ax*cos(theta1_2)*cos(theta23_4)-ay*sin(theta1_2)*...
cos(theta23_4)+az*sin(theta23_4);
theta4_4=atan2(ms4_4,mc4_4);
% 求解关节角5
ms5_1=-ax*(cos(theta1_1)*cos(theta23_1)*cos(theta4_1)+...
sin(theta1_1)*sin(theta4_1))-...
ay*(sin(theta1_1)*cos(theta23_1)*cos(theta4_1)-cos(theta1_1)*sin(theta4_1))...
+az*(sin(theta23_1)*cos(theta4_1));
mc5_1= ax*(-cos(theta1_1)*sin(theta23_1))+ay*(-sin(theta1_1)*sin(theta23_1))...
+az*(-cos(theta23_1));
theta5_1=atan2(ms5_1,mc5_1);
ms5_2=-ax*(cos(theta1_2)*cos(theta23_2)*cos(theta4_2)+...
sin(theta1_2)*sin(theta4_2))-...
ay*(sin(theta1_2)*cos(theta23_2)*cos(theta4_2)-cos(theta1_2)*sin(theta4_2))...
+az*(sin(theta23_2)*cos(theta4_2));
mc5_2= ax*(-cos(theta1_2)*sin(theta23_2))+ay*(-sin(theta1_2)*sin(theta23_2))...
+az*(-cos(theta23_2));
theta5_2=atan2(ms5_2,mc5_2);
ms5_3=-ax*(cos(theta1_1)*cos(theta23_3)*cos(theta4_3)+...
sin(theta1_1)*sin(theta4_3))-...
ay*(sin(theta1_1)*cos(theta23_3)*cos(theta4_3)-cos(theta1_1)*sin(theta4_3))...
+az*(sin(theta23_3)*cos(theta4_3));
mc5_3= ax*(-cos(theta1_1)*sin(theta23_3))+ay*(-sin(theta1_1)*sin(theta23_3))...
+az*(-cos(theta23_3));
theta5_3=atan2(ms5_3,mc5_3);
ms5_4=-ax*(cos(theta1_2)*cos(theta23_4)*cos(theta4_4)+...
sin(theta1_2)*sin(theta4_4))-...
ay*(sin(theta1_2)*cos(theta23_4)*cos(theta4_4)-cos(theta1_2)*sin(theta4_4))...
+az*(sin(theta23_4)*cos(theta4_4));
mc5_4= ax*(-cos(theta1_2)*sin(theta23_4))+ay*(-sin(theta1_2)*sin(theta23_4))...
+az*(-cos(theta23_4));
theta5_4=atan2(ms5_4,mc5_4);
% 求解关节角6
ms6_1=-nx*(cos(theta1_1)*cos(theta23_1)*...
sin(theta4_1)-sin(theta1_1)*cos(theta4_1))...
-ny*(sin(theta1_1)*cos(theta23_1)*...
sin(theta4_1)+cos(theta1_1)*cos(theta4_1))...
+nz*(sin(theta23_1)*sin(theta4_1));
mc6_1= nx*(cos(theta1_1)*cos(theta23_1)*cos(theta4_1)...
+sin(theta1_1)*sin(theta4_1))*cos(theta5_1)...
-nx*cos(theta1_1)*sin(theta23_1)*sin(theta4_1)...
+ny*(sin(theta1_1)*cos(theta23_1)*cos(theta4_1)...
+cos(theta1_1)*sin(theta4_1))*cos(theta5_1)...
-ny*sin(theta1_1)*sin(theta23_1)*sin(theta5_1)...
-nz*(sin(theta23_1)*cos(theta4_1)*cos(theta5_1)...
+cos(theta23_1)*sin(theta5_1));
theta6_1=atan2(ms6_1,mc6_1);
ms6_2=-nx*(cos(theta1_2)*cos(theta23_2)*...
sin(theta4_2)-sin(theta1_2)*cos(theta4_2))...
-ny*(sin(theta1_2)*cos(theta23_2)*...
sin(theta4_2)+cos(theta1_2)*cos(theta4_2))...
+nz*(sin(theta23_2)*sin(theta4_2));
mc6_2= nx*(cos(theta1_2)*cos(theta23_2)*cos(theta4_2)...
+sin(theta1_2)*sin(theta4_2))*cos(theta5_2)...
-nx*cos(theta1_2)*sin(theta23_2)*sin(theta4_2)...
+ny*(sin(theta1_2)*cos(theta23_2)*cos(theta4_2)...
+cos(theta1_2)*sin(theta4_2))*cos(theta5_2)...
-ny*sin(theta1_2)*sin(theta23_2)*sin(theta5_2)...
-nz*(sin(theta23_2)*cos(theta4_2)*cos(theta5_2)...
+cos(theta23_2)*sin(theta5_2));
theta6_2=atan2(ms6_2,mc6_2);
ms6_3=-nx*(cos(theta1_1)*cos(theta23_3)*...
sin(theta4_3)-sin(theta1_1)*cos(theta4_3))...
-ny*(sin(theta1_1)*cos(theta23_3)*...
sin(theta4_3)+cos(theta1_1)*cos(theta4_3))...
+nz*(sin(theta23_3)*sin(theta4_3));
mc6_3= nx*(cos(theta1_1)*cos(theta23_3)*cos(theta4_3)...
+sin(theta1_1)*sin(theta4_3))*cos(theta5_3)...
-nx*cos(theta1_1)*sin(theta23_3)*sin(theta4_3)...
+ny*(sin(theta1_1)*cos(theta23_3)*cos(theta4_3)...
+cos(theta1_1)*sin(theta4_3))*cos(theta5_3)...
-ny*sin(theta1_1)*sin(theta23_3)*sin(theta5_3)...
-nz*(sin(theta23_3)*cos(theta4_3)*cos(theta5_3)...
+cos(theta23_3)*sin(theta5_3));
theta6_3=atan2(ms6_3,mc6_3);
ms6_4=-nx*(cos(theta1_2)*cos(theta23_4)*...
sin(theta4_4)-sin(theta1_2)*cos(theta4_4))...
-ny*(sin(theta1_1)*cos(theta23_4)*...
sin(theta4_4)+cos(theta1_2)*cos(theta4_4))...
+nz*(sin(theta23_4)*sin(theta4_4));
mc6_4= nx*(cos(theta1_2)*cos(theta23_4)*cos(theta4_4)...
+sin(theta1_2)*sin(theta4_4))*cos(theta5_4)...
-nx*cos(theta1_2)*sin(theta23_4)*sin(theta4_4)...
+ny*(sin(theta1_2)*cos(theta23_4)*cos(theta4_4)...
+cos(theta1_2)*sin(theta4_4))*cos(theta5_1)...
-ny*sin(theta1_2)*sin(theta23_4)*sin(theta5_4)...
-nz*(sin(theta23_4)*cos(theta4_4)*cos(theta5_4)...
+cos(theta23_4)*sin(theta5_4));
theta6_4=atan2(ms6_4,mc6_4);
% 整理得到4组运动学非奇异逆解
theta_Med_1 = [ theta1_1,theta2_1,theta3_1,theta4_1,theta5_1,theta6_1;
%theta1_2,theta2_2,theta3_1,theta4_2,theta5_2,theta6_2;
%theta1_1,theta2_3,theta3_2,theta4_3,theta5_3,theta6_3;
%theta1_2,theta2_4,theta3_2,theta4_4,theta5_4,theta6_4;
];
% 将操作关节‘翻转’可得到另外4组解
theta_Med_2 = ...
[ %theta1_1,theta2_1,theta3_1,theta4_1+pi,-theta5_1,theta6_1+pi;
%theta1_2,theta2_2,theta3_1,theta4_2+pi,-theta5_2,theta6_2+pi;
%theta1_1,theta2_3,theta3_2,theta4_3+pi,-theta5_3,theta6_3+pi;
%theta1_2,theta2_4,theta3_2,theta4_4+pi,-theta5_4,theta6_4+pi;
];
theta_Med=[theta_Med_1;theta_Med_2];
end
运行结果
来源：oschina
链接：https://my.oschina.net/u/4345184/blog/4329534
