k8s CLI 操作笔记
- k8s 获取所有的命名空间
namspace可简写为ns
[root@vic-master ~]# kubectl get ns
NAME STATUS AGE
default Active 32d
development Active 31d
kube-node-lease Active 32d
kube-public Active 32d
kube-system Active 32d
- 查看所有的节点
node可简写为no
[root@vic-master ~]# kubectl get no
NAME STATUS ROLES AGE VERSION
vic-master Ready master 33d v1.14.0
vic-node1 Ready <none> 32d v1.14.0
vic-node2 Ready <none> 32d v1.14.0
- 查询 pod ,
pod简写为po, 这里默认的命名空间的 default
[root@vic-master ~]# kubectl get po
NAME READY STATUS RESTARTS AGE
frontend 1/1 Running 0 31d
myapp-54fc6bbfbd-f6cpk 1/1 Running 0 20h
myapp-54fc6bbfbd-zmb2v 1/1 Running 0 20h
ng-dep-679f4c7695-mw62d 1/1 Running 0 21h
redis-php 2/2 Running 0 30d
- 查询指定命名空间的 pod. 获取命名空间
kube-system下的所有 pod
[root@vic-master ~]# kubectl get po -n kube-system
NAME READY STATUS RESTARTS AGE
coredns-8686dcc4fd-gztm2 1/1 Running 1 33d
coredns-8686dcc4fd-xchp6 1/1 Running 1 33d
etcd-vic-master 1/1 Running 0 33d
kube-apiserver-vic-master 1/1 Running 0 33d
kube-controller-manager-vic-master 1/1 Running 9 33d
kube-flannel-ds-amd64-6v4wb 1/1 Running 0 32d
kube-flannel-ds-amd64-nxw8v 1/1 Running 0 32d
kube-flannel-ds-amd64-xplm2 1/1 Running 0 32d
kube-proxy-fr2lv 1/1 Running 0 32d
kube-proxy-m7qn9 1/1 Running 0 33d
kube-proxy-tjwbw 1/1 Running 0 32d
kube-scheduler-vic-master 1/1 Running 8 33d
- 查询所有资源
[root@vic-master ~]# kubectl get all
NAME READY STATUS RESTARTS AGE
pod/frontend 1/1 Running 0 31d
pod/myapp-54fc6bbfbd-f6cpk 1/1 Running 0 20h
pod/myapp-54fc6bbfbd-zmb2v 1/1 Running 0 21h
pod/ng-dep-679f4c7695-mw62d 1/1 Running 0 21h
pod/redis-php 2/2 Running 0 30d
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
service/kubernetes ClusterIP 10.1.0.1 <none> 443/TCP 33d
service/myapp NodePort 10.1.197.115 <none> 80:31611/TCP 20h
service/ng-dep ClusterIP 10.1.115.230 <none> 80/TCP 21h
NAME READY UP-TO-DATE AVAILABLE AGE
deployment.apps/myapp 2/2 2 2 21h
deployment.apps/ng-dep 1/1 1 1 21h
NAME DESIRED CURRENT READY AGE
replicaset.apps/myapp-54fc6bbfbd 2 2 2 21h
replicaset.apps/ng-dep-679f4c7695 1 1 1 21h
- 获取 service
svc简写， 类似获取 pod，同样可以用-n <namespace>来获取指定命名空间下的 service,--all-namepsaces获取所有命名空间下的 service。
[root@vic-master ~]# kubectl get svc
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
kubernetes ClusterIP 10.1.0.1 <none> 443/TCP 33d
myapp NodePort 10.1.197.115 <none> 80:31611/TCP 20h
ng-dep ClusterIP 10.1.115.230 <none> 80/TCP 21h
[root@vic-master ~]# kubectl get svc -n default
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
kubernetes ClusterIP 10.1.0.1 <none> 443/TCP 33d
myapp NodePort 10.1.197.115 <none> 80:31611/TCP 20h
ng-dep ClusterIP 10.1.115.230 <none> 80/TCP 21h
[root@vic-master ~]# kubectl get svc --all-namespaces
NAMESPACE NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
default kubernetes ClusterIP 10.1.0.1 <none> 443/TCP 33d
default myapp NodePort 10.1.197.115 <none> 80:31611/TCP 20h
default ng-dep ClusterIP 10.1.115.230 <none> 80/TCP 21h
kube-system kube-dns ClusterIP 10.1.0.10 <none> 53/UDP,53/TCP,9153/TCP 33d
创建一个可访问的 Web 应用
- 创建一个 deloyment,
vicccc/myapp是我的 Web 镜像，访问8080端口会 返回hello world
[root@vic-master ~]# kubectl create deploy myapp --image=vicccc/myapp
deployment.apps/myapp created
查看 pod 状态 myapp 的状态是 running
[root@vic-master ~]# kubectl get po
NAME READY STATUS RESTARTS AGE
frontend 1/1 Running 0 31d
myapp-688777bd55-nnvws 1/1 Running 0 7m47s
ng-dep-679f4c7695-mw62d 1/1 Running 0 23h
redis-php 2/2 Running 0 31d
- 查看 pod 的详细信息
[root@vic-master ~]# kubectl get po -o wide
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
frontend 1/1 Running 0 31d 10.244.2.2 vic-node2 <none> <none>
myapp-688777bd55-nnvws 1/1 Running 0 10m 10.244.2.8 vic-node2 <none> <none>
ng-dep-679f4c7695-mw62d 1/1 Running 0 23h 10.244.2.6 vic-node2 <none> <none>
redis-php 2/2 Running 0 31d 10.244.1.3 vic-node1 <none> <none>
- 看到 myapp pod 的 ip 地址为
10.244.2.8,直接用 curl 访问8080端口，正常返回 hello world
[root@vic-master ~]# curl 10.244.2.8:8080
hello world
- 当然这个地址只能在本地主机能访问，需要外部机器访问的话需要创建 service, 只要 service name 和 deployment 同名 k8s 就能将两个关联起来
[root@vic-master ~]# kubectl create svc nodeport myapp --tcp=8080:8080
service/myapp created
查看 service 看到 8080 端口被映射到了 31540 端口， 通过本地主机的 IP 加端口便可以访问了。
[root@vic-master ~]# kubectl get svc
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
kubernetes ClusterIP 10.1.0.1 <none> 443/TCP 33d
myapp NodePort 10.1.150.3 <none> 8080:31540/TCP 36s
ng-dep ClusterIP 10.1.115.230 <none> 80/TCP 23h
我的机器的 ip 为 8.16.0.39 , 当然局域网中的主机 通过浏览器等 访问 8.16.0.39:31540 端口也可以获取对应结果
[root@vic-master ~]# curl 8.16.0.39:31540
hello world[root@vic-master ~]#
- 可以用 YAML 的形式查看资源
[root@vic-master ~]# kubectl get deploy myapp -o yaml
apiVersion: extensions/v1beta1
kind: Deployment
metadata:
annotations:
deployment.kubernetes.io/revision: "1"
creationTimestamp: "2020-01-16T08:02:20Z"
generation: 1
labels:
app: myapp
name: myapp
namespace: default
resourceVersion: "4133751"
selfLink: /apis/extensions/v1beta1/namespaces/default/deployments/myapp
uid: 85216899-3836-11ea-b983-000c291cf287
spec:
progressDeadlineSeconds: 600
replicas: 1
revisionHistoryLimit: 10
selector:
matchLabels:
app: myapp
strategy:
rollingUpdate:
maxSurge: 25%
maxUnavailable: 25%
type: RollingUpdate
template:
metadata:
creationTimestamp: null
labels:
app: myapp
spec:
containers:
- image: vicccc/myapp
imagePullPolicy: Always
name: myapp
resources: {}
terminationMessagePath: /dev/termination-log
terminationMessagePolicy: File
dnsPolicy: ClusterFirst
restartPolicy: Always
schedulerName: default-scheduler
securityContext: {}
terminationGracePeriodSeconds: 30
status:
availableReplicas: 1
conditions:
- lastTransitionTime: "2020-01-16T08:02:37Z"
lastUpdateTime: "2020-01-16T08:02:37Z"
message: Deployment has minimum availability.
reason: MinimumReplicasAvailable
status: "True"
type: Available
- lastTransitionTime: "2020-01-16T08:02:20Z"
lastUpdateTime: "2020-01-16T08:02:37Z"
message: ReplicaSet "myapp-688777bd55" has successfully progressed.
reason: NewReplicaSetAvailable
status: "True"
type: Progressing
observedGeneration: 1
readyReplicas: 1
replicas: 1
updatedReplicas: 1
- 扩缩容， 扩展为 3 个副本
[root@vic-master ~]# kubectl scale deploy/myapp --replicas=3
deployment.extensions/myapp scaled
[root@vic-master ~]#
[root@vic-master ~]# kubectl get deploy
NAME READY UP-TO-DATE AVAILABLE AGE
myapp 1/3 3 1 79m
ng-dep 1/1 1 1 24h
[root@vic-master ~]# kubectl get deploy
NAME READY UP-TO-DATE AVAILABLE AGE
myapp 3/3 3 3 80m
ng-dep 1/1 1 1 24h
其他
- 查看当前 k8s 支持的所有 API
[root@vic-master ~]# kubectl api-versions
admissionregistration.k8s.io/v1beta1
apiextensions.k8s.io/v1beta1
apiregistration.k8s.io/v1
apiregistration.k8s.io/v1beta1
apps/v1
apps/v1beta1
apps/v1beta2
authentication.k8s.io/v1
authentication.k8s.io/v1beta1
authorization.k8s.io/v1
authorization.k8s.io/v1beta1
autoscaling/v1
autoscaling/v2beta1
autoscaling/v2beta2
batch/v1
batch/v1beta1
certificates.k8s.io/v1beta1
coordination.k8s.io/v1
coordination.k8s.io/v1beta1
events.k8s.io/v1beta1
extensions/v1beta1
networking.k8s.io/v1
networking.k8s.io/v1beta1
node.k8s.io/v1beta1
policy/v1beta1
rbac.authorization.k8s.io/v1
rbac.authorization.k8s.io/v1beta1
scheduling.k8s.io/v1
scheduling.k8s.io/v1beta1
storage.k8s.io/v1
storage.k8s.io/v1beta1
v1
- 查看当前 k8s 支持的所有资源
[root@vic-master ~]# kubectl api-resources
NAME SHORTNAMES APIGROUP NAMESPACED KIND
bindings true Binding
componentstatuses cs false ComponentStatus
configmaps cm true ConfigMap
endpoints ep true Endpoints
events ev true Event
limitranges limits true LimitRange
namespaces ns false Namespace
nodes no false Node
persistentvolumeclaims pvc true PersistentVolumeClaim
persistentvolumes pv false PersistentVolume
pods po true Pod
podtemplates true PodTemplate
replicationcontrollers rc true ReplicationController
resourcequotas quota true ResourceQuota
secrets true Secret
serviceaccounts sa true ServiceAccount
services svc true Service
mutatingwebhookconfigurations admissionregistration.k8s.io false MutatingWebhookConfiguration
validatingwebhookconfigurations admissionregistration.k8s.io false ValidatingWebhookConfiguration
customresourcedefinitions crd,crds apiextensions.k8s.io false CustomResourceDefinition
apiservices apiregistration.k8s.io false APIService
controllerrevisions apps true ControllerRevision
daemonsets ds apps true DaemonSet
deployments deploy apps true Deployment
replicasets rs apps true ReplicaSet
statefulsets sts apps true StatefulSet
tokenreviews authentication.k8s.io false TokenReview
localsubjectaccessreviews authorization.k8s.io true LocalSubjectAccessReview
selfsubjectaccessreviews authorization.k8s.io false SelfSubjectAccessReview
selfsubjectrulesreviews authorization.k8s.io false SelfSubjectRulesReview
subjectaccessreviews authorization.k8s.io false SubjectAccessReview
horizontalpodautoscalers hpa autoscaling true HorizontalPodAutoscaler
cronjobs cj batch true CronJob
jobs batch true Job
certificatesigningrequests csr certificates.k8s.io false CertificateSigningRequest
leases coordination.k8s.io true Lease
events ev events.k8s.io true Event
daemonsets ds extensions true DaemonSet
deployments deploy extensions true Deployment
ingresses ing extensions true Ingress
networkpolicies netpol extensions true NetworkPolicy
podsecuritypolicies psp extensions false PodSecurityPolicy
replicasets rs extensions true ReplicaSet
ingresses ing networking.k8s.io true Ingress
networkpolicies netpol networking.k8s.io true NetworkPolicy
runtimeclasses node.k8s.io false RuntimeClass
poddisruptionbudgets pdb policy true PodDisruptionBudget
podsecuritypolicies psp policy false PodSecurityPolicy
clusterrolebindings rbac.authorization.k8s.io false ClusterRoleBinding
clusterroles rbac.authorization.k8s.io false ClusterRole
rolebindings rbac.authorization.k8s.io true RoleBinding
roles rbac.authorization.k8s.io true Role
priorityclasses pc scheduling.k8s.io false PriorityClass
csidrivers storage.k8s.io false CSIDriver
csinodes storage.k8s.io false CSINode
storageclasses sc storage.k8s.io false StorageClass
volumeattachments storage.k8s.io false VolumeAttachment
