主要解决 vs2017中,printf无法打印数据的问题。
在keil环境下正常使用printf功能,但是以下的重定向代码在vs2017下使用不了:
#ifdef __GNUC__
/* With GCC/RAISONANCE, small printf (option LD Linker->Libraries->Small printf set to 'Yes') calls __io_putchar() */
#define PUTCHAR_PROTOTYPE int __io_putchar(int ch)
#else
#define PUTCHAR_PROTOTYPE int fputc(int ch, FILE *f)
#endif /* __GNUC__ */
/**
* @brief Retargets the C library printf function to the USART.
* @param None
* @retval None
*/
PUTCHAR_PROTOTYPE
{
/* Place your implementation of fputc here */
/* e.g. write a character to the EVAL_COM1 and Loop until the end of transmission */
HAL_UART_Transmit(&huart1, (uint8_t *)&ch, 1, 0xFFFF);
return ch;
}
vs2017中将以下代码添加入,不需要添加上述在keil中的代码了:
int _write (int fd, char *ptr, int len)
{
HAL_UART_Transmit(&huart1, (uint8_t*) ptr, len, 0xFFFF);
return len;
}
int _read (int fd, char *ptr, int len)
{
*ptr = 0x00; // Flush the character buffer
HAL_UART_Receive(&huart1, (uint8_t*) ptr, 1, 0xFFFF);
return 1;
}
--------------------------------------------------------------------------
开发板:正点原子的stm32f407ZGT6
调试器:JLINK
使用软件:cubemx,visual studio 2017
个人源码如下:
链接:https://pan.baidu.com/s/1MDLE0TCcdZxTgvOvqYduVA
密码:vfg7
参考以下网址:
http://www.stm32cube.com/question/668
