# -*- coding: utf-8 -*- import torch import torch.nn as nn import torchvision import torchvision.transforms as T import PIL import numpy as np from scipy.misc import imread from collections import namedtuple import matplotlib.pyplot as plt from cs231n.image_utils import SQUEEZENET_MEAN, SQUEEZENET_STD #%matplotlib inline def preprocess(img, size=512): transform = T.Compose([ T.Resize(size), T.ToTensor(), T.Normalize(mean=SQUEEZENET_MEAN.tolist(), std=SQUEEZENET_STD.tolist()), T.Lambda(lambda x: x[None]), ]) return transform(img) def deprocess(img): transform = T.Compose([ T.Lambda(lambda x: x[0]), T.Normalize(mean=[0, 0, 0], std=[1.0 / s for s in SQUEEZENET_STD.tolist()]), T.Normalize(mean=[-m for m in SQUEEZENET_MEAN.tolist()], std=[1, 1, 1]), T.Lambda(rescale), T.ToPILImage(), ]) return transform(img) def rescale(x): low, high = x.min(), x.max() x_rescaled = (x - low) / (high - low) return x_rescaled def rel_error(x,y): return np.max(np.abs(x - y) / (np.maximum(1e-8, np.abs(x) + np.abs(y)))) def features_from_img(imgpath, imgsize): img = preprocess(PIL.Image.open(imgpath), size=imgsize) img_var = img.type(dtype) return extract_features(img_var, cnn), img_var # Older versions of scipy.misc.imresize yield different results # from newer versions, so we check to make sure scipy is up to date. def check_scipy(): import scipy vnum = int(scipy.__version__.split('.')[1]) major_vnum = int(scipy.__version__.split('.')[0]) assert vnum >= 16 or major_vnum >= 1, "You must install SciPy >= 0.16.0 to complete this notebook." check_scipy() answers = dict(np.load('style-transfer-checks.npz')) dtype = torch.FloatTensor # Uncomment out the following line if you're on a machine with a GPU set up for PyTorch! #dtype = torch.cuda.FloatTensor # Load the pre-trained SqueezeNet model. cnn = torchvision.models.squeezenet1_1(pretrained=True).features cnn.type(dtype) # We don't want to train the model any further, so we don't want PyTorch to waste computation # computing gradients on parameters we're never going to update. for param in cnn.parameters(): param.requires_grad = False # We provide this helper code which takes an image, a model (cnn), and returns a list of # feature maps, one per layer. def extract_features(x, cnn): """ Use the CNN to extract features from the input image x. Inputs: - x: A PyTorch Tensor of shape (N, C, H, W) holding a minibatch of images that will be fed to the CNN. - cnn: A PyTorch model that we will use to extract features. Returns: - features: A list of feature for the input images x extracted using the cnn model. features[i] is a PyTorch Tensor of shape (N, C_i, H_i, W_i); recall that features from different layers of the network may have different numbers of channels (C_i) and spatial dimensions (H_i, W_i). """ features = [] prev_feat = x for i, module in enumerate(cnn._modules.values()): next_feat = module(prev_feat) features.append(next_feat) prev_feat = next_feat return features #please disregard warnings about initialization def content_loss(content_weight, content_current, content_original): """ Compute the content loss for style transfer. Inputs: - content_weight: Scalar giving the weighting for the content loss. - content_current: features of the current image; this is a PyTorch Tensor of shape (1, C_l, H_l, W_l). - content_target: features of the content image, Tensor with shape (1, C_l, H_l, W_l). Returns: - scalar content loss """ return content_weight * torch.sum((content_current - content_original) ** 2) def content_loss_test(correct): content_image = 'styles/tubingen.jpg' image_size = 192 content_layer = 3 content_weight = 6e-2 c_feats, content_img_var = features_from_img(content_image, image_size) bad_img = torch.zeros(*content_img_var.data.size()).type(dtype) feats = extract_features(bad_img, cnn) student_output = content_loss(content_weight, c_feats[content_layer], feats[content_layer]).cpu().data.numpy() error = rel_error(correct, student_output) print('Maximum error is {:.3f}'.format(error)) content_loss_test(answers['cl_out']) def gram_matrix(features, normalize=True): """ Compute the Gram matrix from features. Inputs: - features: PyTorch Tensor of shape (N, C, H, W) giving features for a batch of N images. - normalize: optional, whether to normalize the Gram matrix If True, divide the Gram matrix by the number of neurons (H * W * C) Returns: - gram: PyTorch Tensor of shape (N, C, C) giving the (optionally normalized) Gram matrices for the N input images. """ N, C, H, W = features.shape f1 = features.view(N, C, -1) f2 = features.view(N, C, -1).permute(0, 2, 1) gram = torch.bmm(f1, f2) if normalize: gram = gram / (H * W * C) return gram def gram_matrix_test(correct): style_image = 'styles/starry_night.jpg' style_size = 192 feats, _ = features_from_img(style_image, style_size) student_output = gram_matrix(feats[5].clone()).cpu().data.numpy() error = rel_error(correct, student_output) print('Maximum error is {:.3f}'.format(error)) gram_matrix_test(answers['gm_out']) # Now put it together in the style_loss function... def style_loss(feats, style_layers, style_targets, style_weights): """ Computes the style loss at a set of layers. Inputs: - feats: list of the features at every layer of the current image, as produced by the extract_features function. - style_layers: List of layer indices into feats giving the layers to include in the style loss. - style_targets: List of the same length as style_layers, where style_targets[i] is a PyTorch Tensor giving the Gram matrix of the source style image computed at layer style_layers[i]. - style_weights: List of the same length as style_layers, where style_weights[i] is a scalar giving the weight for the style loss at layer style_layers[i]. Returns: - style_loss: A PyTorch Tensor holding a scalar giving the style loss. """ # Hint: you can do this with one for loop over the style layers, and should # not be very much code (~5 lines). You will need to use your gram_matrix function. loss = 0 for i in range(len(style_layers)): style_index = style_layers[i] feat = feats[style_index] feat_gram = gram_matrix(feat) target_gram = style_targets[i] loss += style_weights[i] * torch.sum((feat_gram - target_gram) ** 2) return loss def style_loss_test(correct): content_image = 'styles/tubingen.jpg' style_image = 'styles/starry_night.jpg' image_size = 192 style_size = 192 style_layers = [1, 4, 6, 7] style_weights = [300000, 1000, 15, 3] c_feats, _ = features_from_img(content_image, image_size) feats, _ = features_from_img(style_image, style_size) style_targets = [] for idx in style_layers: style_targets.append(gram_matrix(feats[idx].clone())) student_output = style_loss(c_feats, style_layers, style_targets, style_weights).cpu().data.numpy() error = rel_error(correct, student_output) print('Error is {:.3f}'.format(error)) style_loss_test(answers['sl_out']) def tv_loss(img, tv_weight): """ Compute total variation loss. Inputs: - img: PyTorch Variable of shape (1, 3, H, W) holding an input image. - tv_weight: Scalar giving the weight w_t to use for the TV loss. Returns: - loss: PyTorch Variable holding a scalar giving the total variation loss for img weighted by tv_weight. """ # Your implementation should be vectorized and not require any loops! loss = torch.sum((img[:, :, 1:, :] - img[:, :, :-1, :]) ** 2) + \ torch.sum((img[:, :, :, 1:] - img[:, :, :, :-1]) ** 2) return tv_weight * loss def tv_loss_test(correct): content_image = 'styles/tubingen.jpg' image_size = 192 tv_weight = 2e-2 content_img = preprocess(PIL.Image.open(content_image), size=image_size) student_output = tv_loss(content_img, tv_weight).cpu().data.numpy() error = rel_error(correct, student_output) print('Error is {:.3f}'.format(error)) tv_loss_test(answers['tv_out']) def style_transfer(content_image, style_image, image_size, style_size, content_layer, content_weight, style_layers, style_weights, tv_weight, init_random = False): """ Run style transfer! Inputs: - content_image: filename of content image - style_image: filename of style image - image_size: size of smallest image dimension (used for content loss and generated image) - style_size: size of smallest style image dimension - content_layer: layer to use for content loss - content_weight: weighting on content loss - style_layers: list of layers to use for style loss - style_weights: list of weights to use for each layer in style_layers - tv_weight: weight of total variation regularization term - init_random: initialize the starting image to uniform random noise """ # Extract features for the content image content_img = preprocess(PIL.Image.open(content_image), size=image_size) feats = extract_features(content_img, cnn) content_target = feats[content_layer].clone() # Extract features for the style image style_img = preprocess(PIL.Image.open(style_image), size=style_size) feats = extract_features(style_img, cnn) style_targets = [] for idx in style_layers: style_targets.append(gram_matrix(feats[idx].clone())) # Initialize output image to content image or nois if init_random: img = torch.Tensor(content_img.size()).uniform_(0, 1).type(dtype) else: img = content_img.clone().type(dtype) # We do want the gradient computed on our image! img.requires_grad_() # Set up optimization hyperparameters initial_lr = 3.0 decayed_lr = 0.1 decay_lr_at = 180 # Note that we are optimizing the pixel values of the image by passing # in the img Torch tensor, whose requires_grad flag is set to True optimizer = torch.optim.Adam([img], lr=initial_lr) f, axarr = plt.subplots(1,2) axarr[0].axis('off') axarr[1].axis('off') axarr[0].set_title('Content Source Img.') axarr[1].set_title('Style Source Img.') axarr[0].imshow(deprocess(content_img.cpu())) axarr[1].imshow(deprocess(style_img.cpu())) plt.show() plt.figure() for t in range(200): if t < 190: img.data.clamp_(-1.5, 1.5) optimizer.zero_grad() feats = extract_features(img, cnn) # Compute loss c_loss = content_loss(content_weight, feats[content_layer], content_target) s_loss = style_loss(feats, style_layers, style_targets, style_weights) t_loss = tv_loss(img, tv_weight) loss = c_loss + s_loss + t_loss loss.backward() # Perform gradient descents on our image values if t == decay_lr_at: optimizer = torch.optim.Adam([img], lr=decayed_lr) optimizer.step() if t % 100 == 0: print('Iteration {}'.format(t)) plt.axis('off') plt.imshow(deprocess(img.data.cpu())) plt.show() print('Iteration {}'.format(t)) plt.axis('off') plt.imshow(deprocess(img.data.cpu())) plt.show() # Composition VII + Tubingen params1 = { 'content_image' : 'styles/tubingen.jpg', 'style_image' : 'styles/composition_vii.jpg', 'image_size' : 192, 'style_size' : 512, 'content_layer' : 3, 'content_weight' : 5e-2, 'style_layers' : (1, 4, 6, 7), 'style_weights' : (20000, 500, 12, 1), 'tv_weight' : 5e-2 } style_transfer(**params1) # Scream + Tubingen params2 = { 'content_image':'styles/tubingen.jpg', 'style_image':'styles/the_scream.jpg', 'image_size':192, 'style_size':224, 'content_layer':3, 'content_weight':3e-2, 'style_layers':[1, 4, 6, 7], 'style_weights':[200000, 800, 12, 1], 'tv_weight':2e-2 } style_transfer(**params2) # Starry Night + Tubingen params3 = { 'content_image' : 'styles/tubingen.jpg', 'style_image' : 'styles/starry_night.jpg', 'image_size' : 192, 'style_size' : 192, 'content_layer' : 3, 'content_weight' : 6e-2, 'style_layers' : [1, 4, 6, 7], 'style_weights' : [300000, 1000, 15, 3], 'tv_weight' : 2e-2 } style_transfer(**params3) 运行结果如下：
